As a manufacturer and supplier of Wireless Barcode Scanners, our products are widely used across various industries. The warehouse barcode scanner transmits data via Bluetooth, 2.4G and Wi-Fi technologies, eliminating the inconvenience of connection cables. The operator doesn't need to be pulled by the cables and can move freely within a certain range, such as in warehouses, large supermarkets or narrow areas. It is particularly convenient to scan everywhere.
When choosing the right barcode scanner, several factors need to be considered: the type of barcode to be scanned (1D, 2D, or QR code), the wireless or wired connection method, the scanning distance (short, medium, long), and compatibility with existing or integrated scanning systems. Peite scanners come in a variety of models to meet your different needs.
Wireless 2d barcode scanners are generally used in scenarios such as warehousing, supermarkets, logistics sorting, library management, automated production, electronic processing, and parts processing. Different types of scanners are suitable for different working scenarios. When purchasing, you should choose based on your actual needs and application scenarios. Barcodes and scanners are closely related. Wherever barcodes are used, scanners are needed, such as in the clothing industry, the pharmaceutical and drug industry, the payment industry, and so on.
|
The input voltage |
DC 5 volts ± 0.25 volts |
|
|
Power. |
1.60 watts (working);0.40 watts (standby). |
|
|
Current. |
320 mAh (working);80 mAh (standby)5 x/-10% VDC s 350 mA |
|
|
Resolution. |
752 × 480 pixels |
|
|
Scan angle |
± 60 degrees, ± 40 degrees, ± 42 degrees (left, right, back, round). |
|
|
The type of decoding |
1d: UPC-A, UPC-E1, UPC-E0, EAN-13, EAN-8, ISBN (Bookland EAN), ISSN, Code 39, Code 39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Codabar (NW7), Code 128, ISBT 128, Code 93, Code 11 (USD-8), MSI/Plessey, UK/Plessey, UCC/EAN 128, China Post, China Finance, GS1 DataBar (formerly RSS) variants |
|
|
2D: PDF417, MicroPDF417, QR code, DataMatrix |
||
|
How to prompt |
Buzzer,LED |
|
|
The system interface |
RS-232 serial port;USB keyboard;USB imaginary serial port |
|
|
How it was triggered |
Manual. |
|
|
Appearance size |
Long × width× height: 160mm × 66mm ×90mm |
|
|
Weight. |
128g(without cable). |
|
|
Cable standard |
Straight line,1.65 meters |
|
|
The type of interface |
One-in-one line |
|
|
Shell material |
PC+ABS |
|
|
Temperature |
0°C ~ 50°C (working);-40°C~ 60°C (storage) |
|
|
Humidity |
5% to 95%(no condensation). |
|
|
How to set it up |
Manual (scan to set barcodes in turn) |
|
|
Resolution |
3.5mil(high density series),1mil s 0.0254mm |
|
|
Read depth of view |
3.5mil:Code128(9 characters). |
15mm—35mm |
|
5mil:Code39(20 characters). |
33mm—77mm |
|
|
13mil:UPC (12 characters). |
17mm—150mm |
|
|
20mil:Code39(5 characters). |
55mm—195mm |
|
|
6.7mil:PDF417(20 characters). |
25mm—90mm |
|
|
10mil:DM(20 characters). |
15mm—115mm |
|
|
20mil:QR(20 characters). |
9mm—175mm |
|
|
Level of security |
EMC Electromagnetic Compatibility:EN55022,EN55024 Electrical safety:EN60950-1 Waterproof and dust-proof seal rating:IP54 Seismic capacity:5 or more times 1.5 meters of height fell to the cement floor |
|
The 2d barcode reader mainly consists of the upper shell, mainboard, usb interface cable, scanner body, front cover, buttons and bottom buckle. The suppliers of these parts have all passed the inspection. We also use brand-new materials to ensure quality and reduce the after-sales situation for customers. It is precisely because of our strict requirements for quality that we have stable customers for five or six years, and our products are also sold to markets in Southeast Asia, India, Europe, America and so on.
The casing is an important component of the automatic barcode scanner, featuring heat dissipation and shock resistance. It is made of engineering plastic and is manufactured using a precision injection molding machine and a two-color injection molding process to minimize the tolerance of the mold, ensuring that the upper and lower covers, key covers, etc., can close tightly, and wrapping TPE rubber in key areas to meet the IP54 drop resistance standard.
1.Are you a manufacturer? What is the MOQ?
We are the professional thermal printer and symbol wireless barcode scanner manufacturer with full production line. Sample order 1-2 pcs printers are also welcomed.
2.Can you do customize?and how about add our logo?
Yes, ODM/OEM are available. MOQ: 100pcs, we can silk print your logo for free.
3.Can you provide driver and software?
Yes, we can support the driver of Mac/Ios/Windows, SDK, android/ios testing app.
4.Which barcodes can be supported for scanning?
Our barcode scanner supports 1D+2D barcode and QR code scanning, and it is a wireless scanner. It can be connected and used with computers, mobile phones, tablets, POS systems and integrated systems.
